Chevrolet LS3 - SFD58T ITB Kit

Details of Base kit

Chevrolet Individual Throttle Body (ITB) kit for fuel injecting your Chevrolet LS3 engine from Jenvey Dynamics includes eight SFD58/45/0 taper throttle bodies with cross-bank linkage, two EFI inlet manifolds, two billet aluminium fuel rails and eight 20mm long billet airhorns. This kit is ideal for road, track or rally use.

The LS3 engine is widely used in American vehicles such as the Corvette and is popular for use in Motorsport kit and race cars.

CKCT01 - LS3 Crossover

CKCT04 - LS3 Downdraft

CKCT05T - LS7 Downdraft

Kit performance is enhanced by careful positioning of the EFI fuel injectors being located further upstream than standard and directly in the part throttle turbulence of the butterfly.  This allows increased time/distance for improved fuel mixing increasing torque and power where its needed.  Our spindles profiled to minimise cross sectional area at full throttle and an 8 degree shut angle (shallower than most) gives finer control at small throttle openings.  Our kits come built and balanced ready to fit you your engine and win races.

Jenvey Dynamics design, develop and manufacture all products in house often working with leading engine builders.  Uniquely, with our own foundry, all castings are created in the same factory that they are machined and built in.  Our cast systems are significantly lighter than fully CNC parts and all major components are backed up by rig tests of over 1 million cycles.  All our standard kits are proven but our throttle systems are extremely modular allowing bespoke throttle sizes and system lengths. Please order components individually for bespoke application.

This Jenvey kit requires an aftermarket ECU.

Drawing and other information can be found at the bottom of the page

Option and Accessories

This kit includes throttle cable linkage kit.

An idle air system can help make road cars more useable but is not required with electronic actuation

This kit can't be used with stock injectors and must run Bosch long injectors.

We offer a range of injectors but recommend Bosch 412cc for this kit – see our injector sizing chart.

To fit a panel filter to this kit, our LS air filter  is required. ABFLS1-KIT

Price From £3,861.60 £3,218.00

All prices exclude VAT

All prices include VAT

Build Your Kit
Chevrolet LS3 - SFD58T Kit   + £3,861.60 £3,218.00

* Required Fields

Price as Configured

All prices exclude VAT

All prices include VAT

£3,861.60 £3,218.00

View Drawing Manifold Drawing
View Drawing Product Drawing
View Document Fuel System Setup
